1. Low frequency pure sine wave output.
2. Battery voltage: 12V/24V/48V.
3. Built-in automatic 15A AC charger and automatic AC mains switcher.
4. Built with 30A/40A MPPT and effciency more than 99%.
5. High transfer efficiency is above 85%.
6. Built-in Toroidal transfermer, strong overload and impact resistance.
7. 3 working model can be select, charge current can be adjusted.
8. Compatible with sealed, gel, flooded, and lithium (lifepo4) batteries.
Model |
FSI-102 |
FSI-152 |
FSI-202 |
FSI-302 |
FSI-402 |
FSI-502 |
FSI-602 |
| Rated power | 1KW | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW |
| Surge power | 3KW | 4.5KW | 6KW | 9KW | 12KW | 15KW | 18KW |
AC Input & Output |
|||||||
| Voltage | 220VAC | ||||||
| Selectable Voltage Range | 165-275VAC (220VAC) | ||||||
| Frequency Range | 50Hz/60Hz automatic recognition | ||||||
| AC Voltage Regulation (BATT. Mode) |
(DC Batt.mode)220vac±3% | ||||||
| Transfer Time | ≤4ms | ||||||
| Wave Form | Pure Sine Wave | ||||||
| Transformer type | Toroidal | ||||||
| Transfer efficiency | ≥85% | ||||||
Battery |
|||||||
| Battery Voltage | 12V/24V | 12V/24V/48V | 24V/48V | ||||
| Type | Gel/SLA/AGM/ Lithum battery | ||||||
| DC Charge Voltage | 13.6-14.2VDC(12V)/27.2-28.4VDC(24V)/54.4-56.8VDC(48V) | ||||||
| Overcharge Protection | Battery voltage ≧16VDC (12V) ≧32VDC (24V) ≧64VDC (48V), stop charging after 60s alarm | ||||||
Solar Charge & Ac Charger |
|||||||
| Maximum PVArray Working Circuit Voltage | 150VDC | ||||||
| Maximum Pv Array Power | 700W(12V)/1400W(24V) | 1400W(24V)/2800W(48V) | |||||
| Maximum Ac Charge Current | 35A (adjustable) | ||||||
| Maximum Solar Charge Current | 30/50A MPPT (OPTIONAL) | 50A MPPT | |||||
| Maximum Charging Current | 85A | 85A | |||||
Working Mode |
|||||||
| 01 mode | AC mains priority | ||||||
| 02 mode | Energy saving | ||||||
| 03 mode | DC battery priority | ||||||
Physical |
|||||||
| Dimension, D*W*H(MM) |
530*335*250 | 740*335*275 | |||||
| G.W.(KGS) | 16 | 18 | 20 | 22 | 33 | 35 | 36 |
Environment |
|||||||
| Humidity | 0~95%（NO CONDESNSATION) | ||||||
| Operating Temperature | 0~60℃ | ||||||
| Storage Temperature | 0~60℃ | ||||||
| *Product Specifications Are Subject To Change Without Further Notice | |||||||
No information.
A1: Yes, we also provide other solar products, like MPPT Solar Controller, off grid solar inverter, low frequency & high frequency inverter, battery ,solar panel and other accessories related to the solar power system.
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
A3: 5 days for sample; 7-15 days for bulk order.
A4: 2 year warranty.
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
