1. Low frequency pure sine wave output.
2. Battery voltage: 12V/24V/48V.
3. Built-in automatic 35A AC charger and automatic AC mains switcher.
4. Built with 40A/60A/100A MPPT and effciency more than 99%.
5. High transfer efficiency is above 85%.
6. Built-in Toroidal transfermer, strong overload and impact resistance.
7. 5 working model can be select, charge current can be adjusted.
8. Compatible with sealed, gel, flooded, and lithium (lifepo4) batteries.
Model |
TG-152 |
TG-202 |
TG-302 |
TG-402 |
TG-502 |
TG-602 |
| Rated power | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW |
| Surge power | 4.5KW | 6KW | 9KW | 12KW | 15KW | 18KW |
AC Input & Output |
||||||
| Voltage | 220VAC | |||||
| Selectable Voltage Range | 165-275VAC (220VAC) | |||||
| Frequency Range | 50Hz/60Hz automatic recognition | |||||
| AC Voltage Regulation (BATT. Mode) |
(DC Batt.mode)220vac±3% | |||||
| Transfer Time | ≤4ms | |||||
| Wave Form | Pure Sine Wave | |||||
| Transformer type | Toroidal | |||||
| Transfer efficiency | ≥85% | |||||
Battery |
||||||
| Battery Voltage | 12V/24V | 12V/24V/48V | 24V/48V | |||
| Type | Gel/SLA/AGM/Water/Lithium(lifepo4) Battery | |||||
| DC Charge Voltage | 12~16VDC(12V)/20~32VDC(24V)/40~64VDC(48V) | |||||
| Overcharge Protection | Battery voltage ≧16VDC (12V) ≧32VDC (24V) ≧64VDC (48V), stop charging after 60s alarm | |||||
Solar Charge & Ac Charger |
||||||
| Maximum PVArray Open Circuit Voltage | 150VDC | |||||
| Maximum Pv Array Power | 600W(12V)/ 1200W(24V) |
900W(12V)/ 1700W(24V) |
900W(12V)/ 1700W(24V)/ 3400W(48V) |
4200W(24V)/5600W(48V) | ||
| Maximum Ac Charge Current | 35A(adjustable) | |||||
| Maximum Solar Charge Current | 40A MPPT | 60A MPPT | 100A MPPT | |||
| Maximum Charging Current | 75A | 95A | 135A | |||
Working Mode |
||||||
| 01 mode | AC mains priority mode | |||||
| 02 mode | ECO mode | |||||
| 03 mode | DC battery priority mode | |||||
| 04 mode | Generator mode | |||||
| 05 mode | Unattended mode | |||||
Communication Port |
||||||
| Type | RS485, available for wifi box & external control screen | |||||
Physical |
||||||
| Dimension, D*W*H(MM) |
560*440*190 | 650*440*220 | ||||
| G.W.(KGS) | 18 | 21 | 25 | 34 | 36 | 38 |
Environment |
||||||
| Humidity | 0~95%（NO CONDESNSATION) | |||||
| Operating Temperature | 0~60℃ | |||||
| Storage Temperature | 0~60℃ | |||||
| *Product Specifications Are Subject To Change Without Further Notice | ||||||
Model |
TG-152 |
TG-202 |
TG-302 |
TG-402 |
TG-502 |
TG-602 |
| Rated power | 2KVA | 2.5KVA | 3.5KVA | 5.5KVA | 7KVA | 8KVA |
| Surge power | 6KVA | 7.5KVA | 10.5KVA | 16.5KVA | 21KVA | 24KVA |
AC Input & Output |
||||||
| Voltage | 220VAC | |||||
| Selectable Voltage Range | 165-275VAC (220VAC) | |||||
| Frequency Range | 50Hz/60Hz automatic recognition | |||||
| AC Voltage Regulation (BATT. Mode) |
(DC Batt.mode)220vac±3% | |||||
| Transfer Time | ≤4ms | |||||
| Wave Form | Pure Sine Wave | |||||
| Transformer type | Toroidal | |||||
| Transfer efficiency | ≥85% | |||||
Battery |
||||||
| Battery Voltage | 12V/24V | 12V/24V/48V | 24V/48V | |||
| Type | Gel/SLA/AGM/Water/Lithium(lifepo4) Battery | |||||
| DC Charge Voltage | 12~16VDC(12V)/20~32VDC(24V)/40~64VDC(48V) | |||||
| Overcharge Protection | Battery voltage ≧16VDC (12V) ≧32VDC (24V) ≧64VDC (48V), stop charging after 60s alarm | |||||
Solar Charge & Ac Charger |
||||||
| Maximum PVArray Open Circuit Voltage | 150VDC | |||||
| Maximum Pv Array Power | 600W(12V)/ 1200W(24V) |
900W(12V)/ 1700W(24V) |
900W(12V)/ 1700W(24V)/ 3400W(48V) |
4200W(24V)/5600W(48V) | ||
| Maximum Ac Charge Current | 35A(adjustable) | |||||
| Maximum Solar Charge Current | 40A MPPT | 60A MPPT | 100A MPPT | |||
| Maximum Charging Current | 75A | 95A | 135A | |||
Working Mode |
||||||
| 01 mode | AC mains priority mode | |||||
| 02 mode | ECO mode | |||||
| 03 mode | DC battery priority mode | |||||
| 04 mode | Generator mode | |||||
| 05 mode | Unattended mode | |||||
Communication Port |
||||||
| Type | RS485, available for wifi box & external control screen | |||||
Physical |
||||||
| Dimension, D*W*H(MM) |
560*440*190 | 650*440*220 | ||||
| G.W.(KGS) | 18 | 21 | 25 | 34 | 36 | 38 |
Environment |
||||||
| Humidity | 0~95%（NO CONDESNSATION) | |||||
| Operating Temperature | 0~60℃ | |||||
| Storage Temperature | 0~60℃ | |||||
| *Product Specifications Are Subject To Change Without Further Notice | ||||||
Model |
TG-152 |
TG-202 |
TG-302 |
TG-402 |
TG-502 |
TG-602 |
| Rated power | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW |
| 2KVA | 3KVA | 4KVA | 5.5KVA | 7KVA | 8KVA | |
| Surge power | 4.5KW | 6KW | 9KW | 12KW | 15KW | 18KW |
AC Input & Output |
||||||
| Voltage | 220VAC | |||||
| Selectable Voltage Range | 165-275VAC (220VAC) | |||||
| Frequency Range | 50Hz/60Hz automatic recognition | |||||
| AC Voltage Regulation (BATT. Mode) |
(DC Batt.mode)220vac±3% | |||||
| Transfer Time | ≤4ms | |||||
| Wave Form | Pure Sine Wave | |||||
| Transformer type | Toroidal | |||||
| Transfer efficiency | ≥85% | |||||
Battery |
||||||
| Battery Voltage | 12V/24V | 12V/24V/48V | 24V/48V | |||
| Type | Gel/SLA/AGM/Water/Lithium(lifepo4) Battery | |||||
| DC Charge Voltage | 12~16VDC(12V)/20~32VDC(24V)/40~64VDC(48V) | |||||
| Overcharge Protection | Battery voltage ≧16VDC (12V) ≧32VDC (24V) ≧64VDC (48V), stop charging after 60s alarm | |||||
Solar Charge & Ac Charger |
||||||
| Maximum PVArray Open Circuit Voltage | 150VDC | |||||
| Maximum Pv Array Power | 600W(12V)/ 1200W(24V) |
900W(12V)/ 1700W(24V) |
900W(12V)/ 1700W(24V)/ 3400W(48V) |
4200W(24V)/5600W(48V) | ||
| Maximum Ac Charge Current | 60A(adjustable) | |||||
| Maximum Solar Charge Current | 40A MPPT | 60A MPPT | 80A/100A MPPT | |||
| Maximum Charging Current | 75A | 120A | 140A | |||
Working Mode |
||||||
| 01 mode | AC mains priority mode | |||||
| 02 mode | ECO mode | |||||
| 03 mode | DC battery priority mode | |||||
| 04 mode | Generator mode | |||||
| 05 mode | Unattended mode | |||||
Communication Port |
||||||
| Type | RS485, available for wifi box & external control screen | |||||
Physical |
||||||
| Dimension, D*W*H(MM) |
560*440*190 | 650*440*220 | ||||
| G.W.(KGS) | 18 | 21 | 25 | 34 | 36 | 38 |
Environment |
||||||
| Humidity | 0~95%（NO CONDESNSATION) | |||||
| Operating Temperature | 0~60℃ | |||||
| Storage Temperature | 0~60℃ | |||||
| *Product Specifications Are Subject To Change Without Further Notice | ||||||
A1: Yes, we also provide other solar products, like MPPT Solar Controller, off grid solar inverter, low frequency & high frequency inverter, battery ,solar panel and other accessories related to the solar power system.
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
A3: 5 days for sample; 7-15 days for bulk order.
A4: 2 year warranty.
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
