1. Compatible with sealed, gel, flooded, and lithium batteries.
2. Battery voltage (192V/240V/360V/384V).
3. Three-stage charging optimizes battery performance.
4. Maximum effeciency up to 99%.
5. R5485 communication, Communication protocol is available, capable of Wi-Fi remote monitoring.
Model |
AP-100 |
||||||||
| Rated Current | 100A | ||||||||
| Maximum Charging Current |
102A | ||||||||
Mppt Range Operating Voltage |
|||||||||
| 192VDC | 240VDC~600VDC | ||||||||
| 240VDC | 300VDC~600VDC | ||||||||
| 360VDC | 420VDC~850VDC | ||||||||
| 384VDC | 448VDC~850VDC | ||||||||
Maximum Pv Array Power |
|||||||||
| 192VDC | 17920W | ||||||||
| 240VDC | 22400W | ||||||||
| 360VDC | 42000W | ||||||||
| 384VDC | 44800W | ||||||||
Battery |
|||||||||
| Supportable Battery Type | Gel/SLA/AGM/Water battery | ||||||||
| Charging Mode | Three Stages: Constand Current(mppt),equalizing Charge, Floating Charge | ||||||||
| Maximum Efficiency | ≥99% | ||||||||
Communication Portal |
|||||||||
| Communication | RS485, available for wifi box & external control screen | ||||||||
Physical |
|||||||||
| Dimension, D*W*H(MM) |
690*540*360 | ||||||||
| G.W.(KGS) | 45KGS | ||||||||
| *Product Specifications Are Subject To Change Without Further Notice | |||||||||
ion.
A1: Yes, we also provide other solar products, like MPPT Solar Controller, off grid solar inverter, low frequency & high frequency inverter, battery ,solar panel and other accessories related to the solar power system.
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
A3: 5 days for sample; 7-15 days for bulk order.
A4: 2 year warranty.
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
