1. Low frequency pure sine wave output.
2. Battery voltage: 12V/24V/48V.
3. Built-in automatic 35A AC charger and automatic AC mains switcher.
4. Built with 40A/60A MPPT and effciency more than 99%.
5. High transfer efficiency is above 85%.
6. Built-in Toroidal transfermer, strong overload and impact resistance.
7. 3 working model can be select, charge current can be adjusted.
8. Compatible with sealed, gel, flooded, and lithium batteries.
Model |
HSI-2KVA |
HSI-3KVA |
HSI-4KVA |
HSI-5KVA |
HSI-6KVA |
HSI-8KVA |
| Rated power | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW |
| Surge power | 4.5KW | 6KW | 9KW | 12KW | 15KW | 18KW |
AC Input & Output |
||||||
| Voltage | 220VAC | |||||
| Selectable Voltage Range | 165-275VAC (220VAC) | |||||
| Frequency Range | 50Hz/60Hz automatic recognition | |||||
| AC Voltage Regulation (BATT. Mode) |
(DC Batt.mode)220vac±3% | |||||
| Transfer Time | ≤4ms | |||||
| Wave Form | Pure Sine Wave | |||||
| Transformer type | Toroidal | |||||
| Transfer efficiency | ≥85% | |||||
Battery |
||||||
| Battery Voltage | 12V/24V | 24V/48V | ||||
| Type | Gel/SLA/AGM/Lithum battery | |||||
| DC Charge Voltage | 13.6-14.2VDC(12V)/27.2-28.4VDC(24V)/54.4-56.8VDC(48V) | |||||
| Overcharge Protection | Battery voltage ≧16VDC (12V) ≧32VDC (24V) ≧64VDC (48V), stop charging after 60s alarm | |||||
Solar Charge & Ac Charger |
||||||
| Maximum PVArray Open Circuit Voltage | 100VDC | 150VDC | ||||
| Maximum Pv Array Power | 700W(12V)/1400W(24V) | 600W(12V)/ 1200W(24V) |
1700W(24V)/3400W(48V) | |||
| Maximum Ac Charge Current | 20A(Adjustable) | 35A(Adjustable) | ||||
| Maximum Solar Charge Current | 30/50A PWM (optional) | 40A MPPT | 60A MPPT | |||
| Maximum Charging Current | 70A | 75A | 95A | |||
Working Mode |
||||||
| 01 mode | AC mains priority mode | |||||
| 02 mode | ECO mode | |||||
| 03 mode | DC battery priority mode | |||||
Physical |
||||||
| Dimension, D*W*H(MM) |
410*285*150 | 460*335*150 | 490*335*170 | 550*395*170 | ||
| G.W.(KGS) | 18 | 21 | 25 | 34 | 36 | 38 |
Environment |
||||||
| Humidity | 0~95%（NO CONDESNSATION) | |||||
| Operating Temperature | 0~60℃ | |||||
| Storage Temperature | 0~60℃ | |||||
| *Product Specifications Are Subject To Change Without Further Notice | ||||||
Model |
HSI-2KVA |
HSI-3KVA |
HSI-4KVA |
HSI-5KVA |
HSI-6KVA |
HSI-8KVA |
| Rated power | 2KVA | 2.5KVA | 3.5KVA | 5.5KVA | 7KVA | 8KVA |
| Surge power | 6KVA | 7.5KVA | 10.5KVA | 16.5KVA | 21KVA | 24KVA |
AC Input & Output |
||||||
| Voltage | 220VAC | |||||
| Selectable Voltage Range | 165-275VAC (220VAC) | |||||
| Frequency Range | 50Hz/60Hz automatic recognition | |||||
| AC Voltage Regulation (BATT. Mode) |
(DC Batt.mode)220vac±3% | |||||
| Transfer Time | ≤4ms | |||||
| Wave Form | Pure Sine Wave | |||||
| Transformer type | Toroidal | |||||
| Transfer efficiency | ≥85% | |||||
Battery |
||||||
| Battery Voltage | 12V/24V | 24V/48V | ||||
| Type | Gel/SLA/AGM/Lithum battery | |||||
| DC Charge Voltage | 13.6-14.2VDC(12V)/27.2-28.4VDC(24V)/54.4-56.8VDC(48V) | |||||
| Overcharge Protection | Battery voltage ≧16VDC (12V) ≧32VDC (24V) ≧64VDC (48V), stop charging after 60s alarm | |||||
Solar Charge & Ac Charger |
||||||
| Maximum PVArray Open Circuit Voltage | 100VDC | 150VDC | ||||
| Maximum Pv Array Power | 700W(12V)/1400W(24V) | 600W(12V)/ 1200W(24V) |
1700W(24V)/3400W(48V) | |||
| Maximum Ac Charge Current | 20A(Adjustable) | 35A(Adjustable) | ||||
| Maximum Solar Charge Current | 30/50A PWM (optional) | 40A MPPT | 60A MPPT | |||
| Maximum Charging Current | 70A | 75A | 95A | |||
Working Mode |
||||||
| 01 mode | AC mains priority mode | |||||
| 02 mode | ECO mode | |||||
| 03 mode | DC battery priority mode | |||||
Physical |
||||||
| Dimension, D*W*H(MM) |
410*285*150 | 460*335*150 | 490*335*170 | 550*395*170 | ||
| G.W.(KGS) | 18 | 21 | 25 | 34 | 36 | 38 |
Environment |
||||||
| Humidity | 0~95%（NO CONDESNSATION) | |||||
| Operating Temperature | 0~60℃ | |||||
| Storage Temperature | 0~60℃ | |||||
| *Product Specifications Are Subject To Change Without Further Notice | ||||||
Model |
HSI-162 |
HSI-202 |
HSI-302 |
HSI-402 |
HSI-502 |
HSI-602 |
| Rated power | 1.6KW | 2KW | 3KW | 4KW | 5KW | 6KW |
| Surge power | 4.8KW | 6KW | 9KW | 12KW | 15KW | 18KW |
AC Input & Output |
||||||
| Voltage | 220VAC | |||||
| Selectable Voltage Range | 165-275VAC (220VAC) | |||||
| Frequency Range | 50Hz/60Hz automatic recognition | |||||
| AC Voltage Regulation (BATT. Mode) |
(DC Batt.mode)220vac±3% | |||||
| Transfer Time | ≤4ms | |||||
| Wave Form | Pure Sine Wave | |||||
| Transformer type | Toroidal | |||||
| Transfer efficiency | ≥85% | |||||
Battery |
||||||
| Battery Voltage | 12V/24V | 24V/48V | ||||
| Type | Gel/SLA/AGM/Lithum battery | |||||
| DC Charge Voltage | 13.6-14.2VDC(12V)/27.2-28.4VDC(24V)/54.4-56.8VDC(48V) | |||||
| Overcharge Protection | Battery voltage ≧16VDC (12V) ≧32VDC (24V) ≧64VDC (48V), stop charging after 60s alarm | |||||
Solar Charge & Ac Charger |
||||||
| Maximum PVArray Open Circuit Voltage | 150VDC | |||||
| Maximum Pv Array Power | 600W(12V)/ 1200W(24V) |
1700W(24V)/3400W(48V) | ||||
| Maximum Ac Charge Current | 35A(Adjustable) | |||||
| Maximum Solar Charge Current | 40A MPPT | 60A MPPT | ||||
Working Mode |
||||||
| 01 mode | AC mains priority mode | |||||
| 02 mode | ECO mode | |||||
| 03 mode | DC battery priority mode | |||||
Physical |
||||||
| Dimension, D*W*H(MM) |
410*285*150 | 460*335*150 | 490*335*170 | 550*395*170 | ||
| G.W.(KGS) | 18 | 21 | 25 | 34 | 36 | 38 |
Environment |
||||||
| Humidity | 0~95%（NO CONDESNSATION) | |||||
| Operating Temperature | 0~60℃ | |||||
| Storage Temperature | 0~60℃ | |||||
| *Product Specifications Are Subject To Change Without Further Notice | ||||||
No information.
A1: Yes, we also provide other solar products, like MPPT Solar Controller, off grid solar inverter, low frequency & high frequency inverter, battery ,solar panel and other accessories related to the solar power system.
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
A3: 5 days for sample; 7-15 days for bulk order.
A4: 2 year warranty.
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
