1. High frequency pure sine wave output.
2. Battery voltage: 24V.
3. Built-in automatic 60A AC charger and automatic AC mains switcher.
4. Built with 80A MPPT and effciency more than 99%.
5. High transfer efficiency is above 99%.
6. 3 working model can be select, charge current can be adjusted.
7. Compatible with sealed, gel, flooded, and lithium (lifepo4) batteries.
| Model | HVM-243208 | |
| Rated Power | 3.2KW | |
| Line Mode Specifications | ||
| Input Voltage Waveform | Sinusoidal (utility or generator) | |
| Nominal Input Voltage | 230VAC | |
| Low Loss Voltage | 170Vac±7V(UPS);90Vac±7V (Appliances) | |
| Low Loss Return Voltage | 180Vac±7V(UPS);100Vac±7V(Appliances) | |
| High Loss Voltage | 280Vac±7V | |
| High Loss Return Voltage | 270Vac±7V | |
| Max AC Input Voltage | 300Vac | |
| Nominal Input Frequency | 50Hz/60Hz (Auto detection) | |
| Low Loss Frequency | 40+1Hz | |
| Low Loss Return Frequency | 42±1Hz | |
| High Loss Frequency | 65+1Hz | |
| High Loss Return Frequency | 63+1Hz | |
| Output Short Circuit Protection | Circuit Breaker | |
| Efficiency (Line Mode) | >95%( Rated R load, battery full charged ) | |
| Transfer Time | 10ms typical (UPS);20ms typical (Appliances) | |
| Inverter Mode Specifications | ||
| Output Voltage Waveform | Pure Sine Wave | |
| Output Voltage Regulation | 230Vac±5% | |
| Output Frequency | 50Hz | |
| Peak Efficiency | 94% | |
| Overload Protection | 5s@≥150% load; 10s@110%~150% load | |
| Surge Capacity | 2* rated power for 5 seconds | |
| Nominal DC Input Voltage | 24Vdc | |
| Cold Start Voltage | 23.0Vdc | |
| Low DC Warning Voltage @ load < 50% @ load ≥ 50% |
22.0Vdc 21.0Vdc |
|
| Low DC Warning Return Voltage @ load < 50% @ load ≥ 50% |
22.5Vdc 22.0Vdc |
|
| Low DC Cut-off Voltage @ load < 50% @ load ≥ 50% |
20.5Vdc 20.0vdc |
|
| High DC Recovery Voltage | 32Vdc | |
| High DC Cut-off Voltage | 33Vdc | |
| No Load Power Consumption | <35W | |
| Charge Mode Specifications | ||
| Charging Algorithm | 3-Step | |
| AC Charging Current (Max) | 60 Amp(@VP=230Vac) | |
| Flooded Battery | 29.2 | |
| AGM /Gel Battery | 28.2 | |
| Floating Charging Voltage | 27Vdc | |
| MPPT Solar Charging Mode | ||
| INVERTER MODEL | 3KW-24V | |
| Max. PV Array Power | 3000W | |
| Nominal Pv Voltage | 240Vdc | |
| PV Array MPPT Voltage Range | 30~430Vdc | |
| Max.PV Array Open Circuit Voltage | 450Vdc | |
| Max Charging Current (AC charger plus solar charger) |
80Amp | |
| General Specifications | ||
| Safety Certification | CE | |
| Operating Temperature Range | -10’C to 50℃ | |
| Storage temperature | -15°℃~ 60°C | |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
| Dimension(D*W*H)，mm | 405x303x107 | |
| Net Weight, kg | 6.18 | |
A1: Yes, we also provide other solar products, like MPPT Solar Controller, off grid solar inverter, low frequency & high frequency inverter, battery ,solar panel and other accessories related to the solar power system.
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
A3: 5 days for sample; 7-15 days for bulk order.
A4: 2 year warranty.
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
