1. Compatible with sealed, gel, flooded, and lithium batteries.
2. Battery voltage (96V).
3. Three-stage charging optimizes battery performance.
4. Maximum effeciency up to 99%.
5. R5485 communication, Communication protocol is available, capable of Wi-Fi remote monitoring.
Model |
AP-60 |
AP-80 |
AP-100 |
AP-120 |
|
| Rated Current | 60A | 80A | 100A | 120A | |
| Maximum Charging Current | 62A | 82A | 102A | 122A | |
Mppt Range Operating Voltage |
|||||
| 96VDC | 120VDC~200VDC | ||||
Maximum Pv Array Power |
|||||
| 96VDC | 7200W | 9120W | 11200W | 14400W | |
Battery |
|||||
| Supportable Battery Type | Gel/SLA/AGM/Water/Lithium(lifepo4) battery | ||||
| Charging Mode | Three Stages: Constand Current(mppt),equalizing Charge, Floating Charge | ||||
| Maximum Efficiency | ≥99% | ||||
Communication Portal |
|||||
| Communication | RS485, available for wifi box & external control screen | ||||
Physical |
|||||
| Dimension, D*W*H(MM) |
360*260*190 | 570*360*200 | |||
| G.W.(KGS) | 4.5KGS | 13KGS | |||
| *Product Specifications Are Subject To Change Without Further Notice | |||||
A1: Yes, we also provide other solar products, like MPPT Solar Controller, off grid solar inverter, low frequency & high frequency inverter, battery ,solar panel and other accessories related to the solar power system.
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
A3: 5 days for sample; 7-15 days for bulk order.
A4: 2 year warranty.
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
