1. High frequency pure sine wave output.
2. Battery voltage: 48V.
3. Built-in automatic 60A/80A/120A AC charger and automatic AC mains switcher.
4. Built with 100A/120A MPPT and effciency more than 99%.
5. High transfer efficiency is above 99%.
6. 3 working model can be select, charge current can be adjusted.
7. Compatible with sealed, gel, flooded, and lithium (lifepo4) batteries.
| Models | 5.6KW |
| Permitted parallel number | 1~6units |
| AC mode | |
| Rated input voltage | 220/230Vac |
| Input voltage range | (170Vac~280Vac)±2% (90Vac-280Vac)±2% |
| Frequency | 50Hz/60Hz (Auto detection) |
| Frequency Range | 47±0.3Hz~55±0.3Hz(50Hz); 57±0.3Hz~65±0.3Hz (60Hz); |
| Overload/short circuit protection | Circuit breaker |
| Efficiency | >95% |
| Conversion time (bypass and inverter) | 10ms(typical) |
| AC reverse protection | Available |
| Maximum bypass overload current | 40A |
| Inverter mode | |
| Output voltage waveform | Pure sine wave |
| Rated output power (VA) | 5600 |
| Rated output power (W) | 5600 |
| Power factor | 1 |
| Rated output voltage (Vac) | 230Vac |
| Output voltage error | ±5% |
| Output frequency range (Hz) | 50Hz±0.3Hz 60Hz±0.3Hz |
| Maximum Efficiency | >92% |
| Overload protection | (102% < load <125%) ±10%: report error and turn off the output after 1 minutes; (125% < load < 150%) ± 10%: report error and turn off the output after 10 seconds; Load >150% ±10%: report error and turn off the output after 5 seconds |
| Peak power | 11200VA |
| Loaded motor capability | 4HP |
| Rated battery input voltage | 48V(Minimum starting voltage 44V) |
| Battery voltage range | 40.0Vdc~60Vdc±0.6Vdc(undervoltage alarm/turnoff volatage/ overvoltage alarm/overvoltage restoration…settable LCD screen) |
| Power saving mode self consumption | Load≤50W |
| AC charging | |
| Battery type | Lead acid or lithium battery |
| Maximum charge current(can be set) | 0-60A |
| Charge current error | ± 3Adc |
| Charge voltage range | 40-58Vdc |
| Short circuit protection | Circuit breaker and blown fuse |
| Circuit breaker specifications | 40A |
| Overcharge protection | Alarm and turn off charging after 1 minute |
| PV charging | |
| Maximum PV open circuit voltage | 500Vdc |
| PV operating voltage range | 90-500Vdc |
| MPPT voltage range | 90-450Vdc |
| Battery voltage range | 40-60Vdc |
| Maximum PV input power | 6000W |
| Maximum PV input current | 22A |
| PV charging current range (can be set) | 0-100A |
| Charging short circuit protection | Blown fuse |
| Wiring protection | Reverse polarity protection |
| Hybrid charging Max charger current specifications (AC charger+PV charger) | |
| Max charger current(can be set) | 0-100A |
| Certified specifications | |
| Certification | CE(IEC62109-1)/CETL(UL 1741 C22.2 NO.107.1)/FCC/SAA |
| EMC certification level | EN61000 |
| Operating temperature range | -10℃ to 55℃ |
| Storage temperature range | -25℃~60℃ |
| Humidity range | 5% to 95%(Conformal coating protection) |
| Noise | ≤60dB |
| Heat dissipation | Forced air cooling, variable speed of fan |
| Communication interface | USB/RS485(WiFi/GPRS)/Dry contact control |
| Product Size(D*W*H) | 455mm*340mm*140mm |
| Packing Size(D*W*H) | 533mm*423mm*225mm |
| N.W.(Kg) | 11.5KG |
| G.W.(Kg) | 13.0KG |
A1: Yes, we also provide other solar products, like MPPT Solar Controller, off grid solar inverter, low frequency & high frequency inverter, battery ,solar panel and other accessories related to the solar power system.
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
A3: 5 days for sample; 7-15 days for bulk order.
A4: 2 year warranty.
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
