1. Low frequency pure sine wave output.
2. Battery voltage: 12V/24V.
3. Built-in automatic 15A AC charger and automatic AC mains switcher.
4. Built with 30A/40A MPPT and effciency more than 99%.
5. High transfer efficiency is above 85%.
6. Built-in Toroidal transfermer, strong overload and impact resistance.
7. 5 working model can be select, charge current can be adjusted.
8. Compatible with sealed, gel, flooded, and lithium (lifepo4) batteries.
| Model | HTS-102 | HTS-122 |
| Rated Power | 1000W | 1200W |
| Surge Power | 3000W | 3600W |
| AC Input & Output | ||
| Voltage | 120VAC | |
| Selectable Voltage Range | 120VAC±25% | |
| Frequency Range | 50Hz/60Hz automatic recognition | |
| AC Voltage Regulation (BATT. Mode) |
(DC Batt.mode)220vac±3% | |
| Transfer Time | ≤5ms | |
| Wave Form | Pure Sine Wave | |
| Transformer Type | Toroidal | |
| Transfer Efficiency | ≥85% | |
| Battery | ||
| Battery Voltage | 12V/24V | |
| Type | Gel/SLA/AGM/Water/Lithium(lifepo4) Battery | |
| DC Charge Voltage | 12~16VDC(12V)/24~32VDC(24V) | |
| Overcharge Protection | Battery voltage ≧16VDC (12V) ≧32VDC (24V), stop charging after 60s alarm | |
| Solar Charge & Ac Charger | ||
| Maximum PV Array Open Circuit Voltage | Max. 100V | |
| Maximum PV Array Power | 450W(12V)/900W(24V) | 600W(12V)/1200W(24V) |
| Maximum AC Charge Current | 15A | |
| Maximum Solar Charge Current | 30A MPPT | 40A MPPT |
| Maximum Charging Current | 45A | 55A |
| Working mode | ||
| 01 Mode | AC mains priority | |
| 02 Mode | ECO mode | |
| 03 Mode | DC battery priority | |
| 04 Mode | Unattended mode | |
| Communication Port | ||
| Type | RS485, available for wifi box & external control screen | |
| Physical | ||
| Dimension, D*W*H(MM) |
460*339*210 | |
| G.W.(KGS) | 11 | |
| Environment | ||
| Humidity | 0~95%（NO CONDESNSATION) | |
| Operating Temperature | 0~55℃ | |
| Storage Temperature | 0~55℃ | |
| *Product Specifications Are Subject To Change Without Further Notice | ||
No information.
A1: Yes, we also provide other solar products, like MPPT Solar Controller, off grid solar inverter, low frequency & high frequency inverter, battery ,solar panel and other accessories related to the solar power system.
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
A3: 5 days for sample; 7-15 days for bulk order.
A4: 2 year warranty.
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
